FAG dryers have been designed for continuous separation of water vapor from compressed air thus reducing dew point.
| Rated Air processing Volume | 1-300Nm3/min |
| Operation pressure | 0.6~0.8MPa(0.8-3.0Mpa as option) |
| Operating temperature range | 1.5℃ to 55 ℃ |
| Dew point | -20℃~ -70℃ |
| Inlet Air Temperature | <38℃ |
| Cooling Way | Water Cooling/Air Cooling |
| Customization | Stainless steel, ATEX, ASME, CE |
FAG dryers have been designed for continuous separation of water vapor from compressed air thus reducing dew point. Drying consist of two steps. Refrigerant dryer first eliminates large majority of water and reduces dew point down to +3℃. Further reduction of dew point is carried out by adsorption dryer. Operation of dryer is simpler compared to conventional heat regenerated adsorption dryer while average compressed air losses present only up to 3-6%.
BODA focuses on the global market and provides our customers with products suitable for the local market:
Whether selecting a product from our catalog or seeking engineering assistance for your application, you can talk to our customer service center about your sourcing requirements.
